16. BRAKE SYSTEM MXU 500IRS
:
Refer to the "REAR PARKING
SYSTEM" section in this chapter to
install the left master cylinder holder.
Install the brake fluid hose with the
attaching bolt and two new sealing washers,
then tighten the bolt to the specified torque.
Torque: 3.5 kgf-m (35 Nm, 25 lbf-ft)
Apply lightweight lithium-soap base grease
to the dust boot in the master cylinder, then
install the brake lever.
Apply lightweight lithium-soap base grease
to the bolt, then install and tighten the bolt
and nut securely.
Fill the brake reservoir with the specified
brake fluid and bleed air from the brake
system (refer to the "FRONT BRAKE
FLUID CHANGE/AIR BLEED" section
or "REAR BRAKE FLUID
CHANGE/AIR BLEED" section or
"COMBINATION BRAKE FLUID
CHANGE/AIR BLEED " section in this
chapter).
Apply grease to the dust boot
Install the brake reservoir cap.
16-26
