          16. BRAKE SYSTEM                                MXU 500IRS

 ASSEMBLY

  Wash the brake caliper components
    with new brake fluid before
    reassembly.
    Do not wipe the brake fluid off with a
    rag after washing the components.
    When washing the components, use
    the specified brake fluid (DOT 4).
    Never use different types of fluid or
    cleaning solvents such as gasoline,
    kerosine, etc.
    Apply brake fluid to all of the seals,
    brake caliper bore and piston before
    reassembly.


 Apply silicone grease to the caliper bracket
 pins.




16-39
