2. FRAME COVERS/EXHAUST MUFFLER AGILITY CITY 50 2T FRAME BODY COVER REMOVAL Screws Battery Cover Screws Remove the two screws on the battery cover. Remove the battey cover Remove the six screws on the center cover Remove the center cover Center Cover Bolts Remove the three bolts attaching the rear carrier. Remove the rear carrier. Rear Carrier Rear Step Remove the two bolt attaching the lefe and right rear step. Remove the rear step Bolts Left Side Skirt Remove the six screws attaching the left side and right side skirt Remove the left side and right side skirt During removal, do not pull the joint claws forcedly to avoid damage. When installing, be sure to connect the seat lock wire. Screws Right Side Skirt 2-3
