4. LUBRICATION SYSTEM AGILITY CITY 50
Install the pump driven gear and secure it Pump Driven Gear
with the circlip.
Torque: 0.81.2kg-m
Circlip
Right Crankcase Cover
Install the right crankcase cover and tighten
the eight bolts.
Torque: 0.8~1.2kgf-m
Diagonally tighten the bolts in 23
times.
Bolts
4-6
