2. EXHAUST MUFFLER/FRAME COVERS Downtown 300i ABS
SERVICE INFORMATION
GENERAL INSTRUCTIONS
· When removing frame covers, use care not to pull them by force because the cover joint claws
may be damaged.
· Make sure to route cables and harnesses according to the Cable & Harness Routing.
TORQUE VALUES
Exhaust muffler pipe nuts 1.8~2.2 kgf-m
Exhaust muffler brake /RR Frok 3.2~3.8 kgf-m
RR fork/Engine case 3.0~4.0 kgf-m
TROUBLESHOOTING
Noisy exhaust muffler
· Damaged exhaust muffler
· Exhaust muffler joint air leaks
Lack of power
· Caved exhaust muffler
· Clogged exhaust muffler
· Exhaust muffler air leaks
2-1
