4. FUEL SYSTEM K-PIPE 50
AIR CLEANER REMOVAL
Remove the front cover (page 14-3).
Remove the screw attaching the carburetor.
Remove the air cleaner case by removing the
attaching bolts.
Screw
Screw
Screw
Element
.
Remove the four screws with the air cleaner case
cover.
Element Holder Air Cleaner Case Cover
Remove the element and the element holder
from the air cleaner case.
INSTALLATION
Install the air cleaner case in the reverse order of
removal.
4-4
