11.CRANKSCASE/CRANKSHAFT/
BALANCE SHAFT ATV 300/250
Remove balance shaft from the left Balance Shaft
crankcase.
Clean off all gasket material from the
crankcase mating surfaces.
Avoid damaging the crankcase mating
surfaces.
Inspect the balance shaft gear teeth.
Burrs/chips/roughness/wear Replace.
CRANKSHAFT INSPECTION
Inspect the crankshaft gear teeth.
Burrs/chips/roughness/wear Replace.
Measure the connecting rod small end I.D.
Service Limit: 17.06 mm (0.6824)
11-4
