1. GENERAL INFORMATION PEOPLE 250 TORQUE VALUES STANDARD TORQUE VALUES Item Torque (N-m) Item Torque (N-m) 5mm bolt, nut 4.56 5mm screw 3.55 6mm bolt, nut 812 6mm screw, SH bolt 711 8mm bolt, nut 1825 6mm flange bolt, nut 1014 10mm bolt, nut 3040 8mm flange bolt, nut 2430 12mm bolt, nut 5060 10mm flange bolt, nut 3545 Torque specifications listed below are for important fasteners. ENGINE Item Q`ty Thread dia.(mm) Torque (N-m) Remarks Cylinder head bolt A 2 8 8.9 Double end bolt Cylinder head bolt B 2 8 8.9 Double end bolt Oil filter screen cap 1 30 12.7 Apply oil to threads Cylinder head cap nut 4 8 24.5 Valve adjusting lock nut 2 5 8.8 Cam chain tensioner slipper bolt 1 6 8.8 Oil bolt 1 12 14.7 Clutch outer nut 1 12 53.9 Clutch drive plate nut 1 12 53.9 Flywheel nut 1 14 58.8 Oil pump bolt 2 5 3.9 Cylinder head cover bolt 4 6 11.8 Spark plug 1 10 17.2 Cam chain tensioner bolt 1 6 11.8 Water pump impeller 1 8 11.8 Drive face nut 1 12 93 Transmission case cover bolt 9 8 20 Gear oil check bolt 1 8 10 1-7
