          13. FUEL INJECTION SYSTEM                                                      People GT 300i



 EFI SELF-DIAGNOSIS CHECK
 ENGINE LAMP (CELP) FAILURE
 CODES                                           If more than a damaged part has occurred, the
 The "CELP" denotes the failure codes.           "CELP" begins blinking in order.
 When the indicator lights for one second that
 is equal to ten.                                For example: If the indicator blinks six times,
 For example: one longer blink illumination      then shows one second illumination and two
 and two shorter blinks (0.5 second x 2) of      blinks, so there are two failures have occurred.
 the indicator is equal to 12 blinks. Follow     Follow code 6 and 12.
 code 12.




13-7
