8. A.C. GENERATOR ATV 50
Fan Cover
A.C. GENERATOR REMOVAL
Remove the three bolts attaching the fan
cover to remove the fan cover.
Bolts
Remove the cooling fan by removing the Bolt
four bolts.
Cooling Fan
Nut
Hold the flywheel with an universal holder
and then remove the flywheel nut.
Special tool:
Universal holder A120E00017
Universal Holder
8-3
