13. FUEL SYSTEM/CARBURETOR/
FUEL PUMP/ FUEL TANK PEOPLE 250
AUTO BYSTARTER INSPECTION
Check the auto bystarter valve and needle for
nicks, wear or damage.
If any faulty part is found, replace the auto
bystarter with a new one.
Bystarter Needle Bystarter Valve
AIR CUT-OFF VALVE (A.C.V.) Air Cut-off Valve Cover
A.C.V. REMOVAL
Remove the two screws and the air cut-off
valve cover.
Screws
Diaphragm
Remove the spring, diaphragm and O-rings.
Inspect the diaphragm and spring for wear or
damage.
Cover Spring
13-12
