11. FUEL SYSTEM STRYKER 125/150
Remove the bolts and screws attaching the
Screws
right and left decorative covers the fuel tank.
Remove the right and left decorative covers.
Bolts
Disconnect the fuel tube and remove the
bolt on the end of the fuel tank.
Disconnect the fuel unit wire connector.
Remove the fuel tank.
Fuel Unit Wire Connector Bolts
Disconnect the fuel tube and vacuum tube Auto Fuel Valve Vacuum Tube
at the auto fuel valve.
Fuel Tube
11-16
