7. KICK STARTER/DRIVE PULLEY/
CLUTCH/DRIVEN PULLEY SUPER 9 50
Drive in a new needle bearing into the Bearing Driver Pilot
driven face with the mark facing up.
Outer Driver
CLUTCH/DRIVEN PULLEY ASSEMBLY Driven Pulley Oil Seal
First install the movable driven face onto
the driven face. Then, install the guide
roller pins, O-rings and a new oil seal.
O-rings Guide Roller Pin
Install the seal collar.
Seal Collar
7-15
