10. A.C. GENERATOR/STARTER CLUTCH DOWNTOWN 125i A.C.GENERATOR REMOVAL Drain the engine oil (refer to the "ENGINE OIL" section in the chapter 3). Disconnect the generator connectors Remove ten bolts attached the right crankcase cover and then remove the cover. Remove two dowel pins and gasket. Dowel Pins Gasket Stator Remove two pulse coil mount screws. Remove three stator mount bolts, grommet and the stator attached the right crankcase cover. Pulser Coil 10-3
