2. FRAME COVERS/EXHAUST MUFFLER MXU 250R/300R Screws/Nuts Remove 6 screws/nuts, 4 mounting bolts and the right footboard. During removal, do not pull the joint claws forcedly to avoid damage. Installation is in the reverse order of removal. Mounting Bolts Bolts Screw RIGHT/LEFT SIDE COVER REMOVAL/INSTALLATION Open the seat (see page 2-3). Remove the right/left footboard (see page 2- 5). Remove the screw, two mounting bolts and right side cover. Screw Bolts Remove the screw, two mounting bolts and left side cover. During removal, do not pull the joint claws forcedly to avoid damage. Installation is in the reverse order of removal. 2-6
