2. FRAME COVERS/EXHAUST MUFFLER ATV 50
FRONT COVERS REMOVAL Front Cover
Remove the two screws on the front cover.
Screws
Remove the left and right front fender under
bolt.
Remove the front cover.
Bolts
Right Front Cover
FRONT FENDER REMOVAL
Remove screws attaching the left and right
front fender.
Remove the left and right front fender.
Screws
During removal, be careful not to
damage the joint claws.
Left Front Cover Screws
2-4
