          5. ENGINE REMOVAL/INSTALLATION                                   People GT 300i


 Remove the spark plug cap.




                                                Spark Plug Cap




                                                        Radiator Hose
 Disconnect the lower radiator hose from
 lower radiator pipe.




 Remove the right and left rear cushion lower
 mount bolts.

 Torque: 4.0 kgf-m (40N-m)




                                                                        Mount Bolt




                                                                            5-4
