14. HYDRAULIC BRAKE STRYKER 125/150 BRAKE MASTER CYLINDER Fluid Tube Bolt REMOVAL Drain the brake fluid from the hydraulic brake system. Do not splash brake fluid onto any rubber, plastic and coated parts. When working with brake fluid, use shop towels to cover these parts. Remove the two master cylinder holder bolts and remove the master cylinder. When removing the brake fluid tube bolt, Fluid Tube Bolts be sure to place towels under the tube and plug the tube end to avoid brake fluid leakage and contamination. DISASSEMBLY Remove the piston rubber cover and snap ring from the brake master cylinder. Snap Ring Pliers Remove the washer, main piston and spring from the brake master cylinder. Master Cylinder Main Piston Clean the inside of the master cylinder and brake reservoir with brake fluid. Spring Snap Ring 14-7
