9. A.C. GENERATOR SUPER 9 50
Remove the A.C. generator flywheel using Lock Nut Wrench
the flywheel puller.
Flywheel Puller
Remove the A.C. generator wire connector. A.C. Generator Wire Connector
Remove the two pulser coil bolts and pulser Stator Wire Clamp
coil from the right crankcase.
Remove the pulser coil wire clamp from the
right crankcase.
Remove the two bolts attaching the A.C.
generator stator.
Be careful not to damage the discon-
nected wire.
Pulser Coil
9-4
