12. CARBURETOR/FUEL PUMP
Screws Auto Bystarter
AUTO BYSTARTER INSTALLATION
Install the auto bystarter into the carburetor
body until it bottoms..
Install the set plate and then tighten the two
screws.
Set Plate
Screws
FLOAT CHAMBER
Remove the two float chamber screws and
the float chamber.
O-ring
Remove the screw and O-ring.
Remove the float pin, float and float valve.
Float Pin Float
12-8
